Revvi 24" Electric Bike

Lightweight Design

Only 30.6kg – built stronger for bigger riders while maintaining balance and control.

Triple Speed Modes

15.5 / 22 / 30 MPH (3 speed settings)

Tyres

Proper pneumatic tyres (24" aggressive knobbly) for grip on all surfaces.

Brushless Motor

High efficiency 48V 1000W brushless motor with peak 1500W power for maximum performance.

Motor

Motor Rated Power - 48V 1000w brushless hub motor

Motor Peak power: 48V 1500w brushless hub motor 132 N·m Torque

Battery

48V 15AH Lithium ion

Transmission

Hub Motor

Battery Range

Slow speed: Approx 1h 20m constant use

Medium speed: Approx 50m constant use

Fast speed: Approx 30m constant use

(Please note battery range will vary depending on the speed setting, rider weight and riding conditions.)

Battery Charge Time

3hrs

Max Speed

15.5 / 22 / 30 MPH (3 speed settings)

Frame

Aluminium alloy+Forged swing arm with linkage

Front Forks / Travel

RST Compression / Rebound Suspension forks – 140mm travel

Rear Shock / Travel

RST Air Shock Compression / Rebound

Brake

Front and rear hydraulic disc brakes

Handle Bar

Alloy

Stem

Alloy

Grip

Rubber

Tire

Aggressive knobbly 24"

Fork

RST Compression / Rebound Suspension forks – 140mm travel

Rim

Spoked rim 24"

Net Weight

30.8kg

Max Load

75kg
