SQ LAB Saddle 602 Ergolux active 2.0

Did you already measure your sitbones?

A prerequisite for maximum comfort and relief is the coordinated saddle width, so that it is guaranteed that your seat bones lie completely on the saddle. This is the only way to properly relieve the sensitive perineal area in men and the usually lower pubic arch in women.

• Proven trekking / touring saddle for medium to long distances with a new surface for the sit bones.
• Double step saddle shape (Ergolux) for more support in the rear area and more relief in the front.
• Active saddle technology supports pedaling, increases comfort and relieves the spinal discs.
• Active saddle technology adjustable to the rider's weight with the two comfort sticks.
• Unisex saddle. Available in the saddle widths 14, 15, 16 and 17 cm, approved up to 130 kg rider weight.

Technical specifications at a glance

ARTICLE NUMBER(S) 2427 / 2428 / 2429 / 2430

AREA OF USE/BICYCLE TYPE TREKKING

WEIGHT(S) IN G APPROX. 440 / 443 / 454 / 468

ACTIVE TECHNOLOGY YES - COMFORT

MOUNTING HEIGHT IN MM APPROX. 78

SIZE(S) IN CM (EFFECTIVE SADDLE WIDTH) 14 / 15 / 16 / 17

LENGTH IN MM APPROX. 280

MATERIAL RAILS CRMO (SOLID)

MATERIAL BASE POLYPROPYLENE COMPOUND (PP)

MATERIAL PADDING LIGHT FOAM

MATERIAL COVER MICROFIBRE

HARDNESS IN SQ-SHORE 45

RELIEF OF PERINEAL AREA IN % 70

MAXIMUM LOAD IN KG 130

MAXIMUM TORQUE IN NM 18

E-BIKE READY YES

DIN/ASTM CATEGORIES 2

GENDER UNISEX

Description at a glance

The 602 ERGOLUX® active 2.0, the trekking and touring saddle for medium to long distance riding. Compared to the former performance ERGOWAVE® models, the 602 ERGOLUX® 2.0 active offers greater padding volume which makes for softer feeling foam. The dual waves make the supporting surface significantly larger than before, keeping the sit bones from sinking less deeply into the sitting area. As a result, the Ergolux® does not have the disadvantages that normally come with softer foam.

The first level accommodates the rear part of the sit bones offering perfect support for improved force transmission onto the pedal. The second level ideally accommodates the unburdened ischial rami, thereby ensuring the best-possible pressure distribution. Due to the saddle nose sitting lower, the perineal and front area of the pubic bone and pubic arch have more free space.

Thanks to the proven SQlab active system which allows the saddle to follow the pedalling movements of the rider, comfort is increased, less strain is placed on the inter- vertebral discs and pressure on the sit bones is further reduced. Thanks to the proven SQlab active system which allows the saddle to follow the pedaling movements of the rider, comfort is increased, less strain is placed on the inter- vertebral discs and pressure on the sitbones is further reduced. The flex and active movement can be adjusted to the body weight with the comfort sticks in the active dampener.

Perfect grip

The raised rear results in more grip toward the rear and provides more efficient force transfer.

Comfortable Sitting Position

The wave-shaped elevation of the ERGOLUX® that extends frontward has a shape that fits perfectly to most bulbous ishial branches. The enlarged, less intermittent support surface provides optimal pressure distribution inside the ischial branches.

Lower saddle nose

The lower-lying saddle nose accordingly presses less on sensitive positions. Equally so for both men and women.

SQlab active system comfort

The SQlab technology relieves strain on intervertebral discs and sit bones. The active movement can be adjusted via two comfort sticks.

Low and flat

The flat saddle nose has a slight curvature which provides maximum contact area providing and associated reduced pressure. This shape provides a narrow saddle nose which minimizes chafing on the inside of the thighs while pedaling.
